Scissor Lift 32’ 32”
The Genie® GS™-3232 E-Drive slab scissor lift is an electric model ideal for operation in emission and sound-sensitive indoor and outdoor jobsites where space is limited. The standard, state-of-the-art Genie AC electric E-Drive system offers unmatched efficiency and runtime on installation, maintenance and construction jobs, especially when a significant amount of driving is required.
Overview
- Powerful AC electric drive motors for unmatched driving performance and industry-leading runtime per battery charge
- Quiet, zero-emission electric operation
- Easy to maneuver in tight spaces
- Automatic leveling hydraulic outriggers level machine on slopes up to 5˚
- 25% gradeability with 14° breakover angle to easily get up slopes and loading ramps
- Large platform workspace with 36 in (0.91 m) roll-out platform extension
- Swing out components trays for easy access
- User-friendly Smart Link™ dual-zone controls for indoor and outdoor use
Features
- Max Working Height: 38 ft 1 in | 11.78 m
- Platform Capacity: 500 lb | 227 kg
- Machine Width: 2 ft 8 in | 0.81 m
- Machine Length: 8 ft | 2.44 m
- Weight: 5,367 lb | 2,434 kg
Options
Chassis Options
- AGM maintenance-free batteries
- Automotive-style horn
- Biodegradable hydraulic oil
- Biodegradable hydraulic oil(for GS-3232, GS-3246)
- Power inverter, 800W, 24V DC, 120V AC, 60 Hz
Certification Options
- EE Certification
Platform Options
- Air line to platform: ? in. inner diameter
